Stock Suspension G Body Lower Torque Boxes (Assembled)
Description
These assembled Lower Torque Box provides precision adjustability through its multi-position mounting system in G body (78-88) applications. This replacement component incorporates dual row adjustment capabilities and reinforcement doublers for exceptional structural rigidity. Designed for heim joint control arm applications, this package delivers complete installation readiness with all required hardware and precision-machined spacers included.
Lower torque box bracket kit specs:
- 3/16" main brackets
- 1/8" main bracket doublers
- 1/2" Bolt holes
- Designed for a 1.865" spacing between the brackets
Includes:
- Welded lower torque boxes (1ea drivers side, 1ea passenger side)
- GR8 bolts and misalignment spacers
***Welding & Fabrication required for install***
